Product features
Coriolis force two-phase flow meter applicable to oil and gas two-phase measurement
● Based on Coriolis force principles, with a high precision.
● Measurement based on gas/liquid two-phase mass flow rate.
● Wide measurement range, gas volume fraction (GVF): 80%-100%.
● No radioactive source.
产品参数
Specifications
Model | AMPF-C050 |
Nominal diameter | 2"-4" DN50-DN100 |
Measurinq range | Gas phase: (0~5x105)Nm3/d/liquid phase: (0〜1000)Nm3/d |
Accuracy of measurement | Gas phase: ±10%/Liquid phase : ±5%/ |
GVF | (80-100) % |
Desiqn pressure： | 6.3MPa~10MPa |
Answer the liquid material | 316L, (Customizable: Monel 400, Hastelloy C22, etc.) |
Safety and Protection | Ex d ib ⅡB T5 Gb |
Data transmission mode: | RS485 |
Ambient Temp | -40°C~+55°C |
主要用途
Multi-flow parameters of gas/oil/oil-gas well two-phase flow products, such as gas/liquid ratio, gas flow, liquid volume and total flow, realize continuous real-time, high-precision and stable measurement/monitoring.
资料下载
AMF Series Coriolis Mass Flowmeter User Guide MAT-AMF.C10-1.3A English.pdf
